CXF Hydrated Lime Classifier is a high-efficiency vortex combined classifying equipment,which is upgraded from the conventional powder classifier used in cement clinker milling process based on many years of working exprience in the lime hydration area. It is more suitable for hydrated lime classification in medium and large lime hydration plants. CXF powder classifier could very efficiently remove the non-reactive grits from the hydrated lime while leaving minimum powder in it, and the output fineness can be easily adjusted based on requirement.
CXF Hydrated Lime Classifier is a high-efficiency vortex combined classifying equipment,which is upgraded from the conventional powder classifier used in cement clinker milling process based on many years of working exprience in the lime hydration area. It is more suitable for hydrated lime classification in medium and large lime hydration plants. CXF powder classifier could very efficiently remove the non-reactive grits from the hydrated lime while leaving minimum powder in it, and the output fineness can be easily adjusted based on requirement.
Typical Technical Data
| Model | Particle size R0.045（%） |
Air flow （m3/h） |
Air Pressure of Fan （Pa） |
Classifier Motor （kw） |
Circulating Fan Motor （Kw） |
Output capacity （t/h） |
| CXF-350 | 0~3 | 21000 | 3847 | 18.5 | 45 | 5~6 |
| CXF-500 | 0~3 | 30000 | 3996 | 22 | 55 | 9~10 |
| CXF-650 | 0~3 | 39000 | 3994 | 30 | 75 | 12~13 |
| CXF-800 | 0~3 | 48000 | 3829 | 37 | 90 | 15~17 |
| CXF-1000 | 0~3 | 60000 | 3861 | 45 | 110 | 20~22 |
| CXF-1250 | 0~3 | 75000 | 3879 | 55 | 132 | 25~27 |
| CXF-1500 | 0~3 | 90000 | 4029 | 55 | 160 | 30~35 |
