This kind of crusher can crush many kinds of materials with max feed size less than 500mm and crushing strength less than 350 MPa. It has the features of high ratio of crushing, reliable working, easy to maintenance, etc. The final products are with cubic shapes and are the ideal equipment for construction the highway and water and electricity construction. In addition, impact crushers are more suitable to process granite, limestone, bank gravel etc. in the area of highway construction, water conservancy project and architecture.
This kind of crusher can crush many kinds of materials with max feed size less than 500mm and crushing strength less than 350 MPa. It has the features of high ratio of crushing, reliable working, easy to maintenance, etc. The final products are with cubic shapes and are the ideal equipment for construction the highway and water and electricity construction. In addition, impact crushers are more suitable to process granite, limestone, bank gravel etc. in the area of highway construction, water conservancy project and architecture.
| Model | Specification (mm) |
Feed Inlet Size (mm) | Max Feeding Size (mm) | Capacity (t/h) |
Motor Power (kw) |
Outer dimensions L×W×H (mm) |
Total weight (t) |
| PF-0807 | Φ750×700 | 400×730 | 300 | 15-30 | 45 | 2210×1490×2670 | 8.1 |
| PF-1007 | Φ1000×700 | 400×730 | 300 | 25-60 | 55 | 2400×1558×2660 | 9.5 |
| PF-1010 | Φ1000×1050 | 400×1080 | 350 | 50-80 | 75 | 2400×2250×2720 | 12.2 |
| PF-1210 | Φ1250×1050 | 580×1080 | 350 | 70-120 | 95 | 2690×2330×2890 | 14.1 |
| PF-1214 | Φ1250×1400 | 580×1430 | 400 | 110-180 | 132 | 2690×2688×2890 | 18.6 |
| PF-1315 | Φ1320×1500 | 860×1520 | 500 | 160-250 | 185 | 3096×3273×2667 | 23.4 |
| PF-1320 | Φ1320×2000 | 860×2030 | 600 | 200-310 | 300 | 3280×3570×2920 | 27.5 |
